Inductive Sensor Ifm GF762S
IFM CATEGORIES
Inductive Sensor GF762S
Brand: Ifm
Product Code: GIFK4003B2PS/SIL2/AM/US
- Compliant with the following norms: EN 60947-5-3, IEC 61508, and ISO 13849
- Integration with safety PLCs, safe AS-i modules, or secure evaluation units
- Guaranteeing the safety of both the operator and the equipment
- Sensing surface made of stainless steel
- Elevated protection rating
Contact via Zalo
Phone call
Product characteristics
| Electrical engineering design | PNP | ||
| Activate area[mm] | 0...1.5 | ||
| Housing | Screw-type | ||
| measurements[mm] | M12 x 1 / L = 60 | ||
| System | gold-plated terminals; complete metal enclosure | ||
| Mode of operation | continuous operation | ||
| safety-critical sub-function | Safe state with proper damping (s > sAs (sar)) | ||
| Application | continuous cleaning with harsh detergents; routine cleaning procedures | ||
| Display |
|
Tests / approvals
| Adjustment coefficient | steel: 1 / stainless steel: 0.6 / brass: 0.7 / aluminum: 0.6 / copper: 0.3 |
Outputs
| Electrical engineering design | PNP |
| Max. voltage drop at switching output DC[V] | 2.5 |
| Count of OSSD outputs | 2 |
| Max. current capacity for each OSSD output[mA] | 50 |
| Output information | Interface type C category 1 |
| Output voltage of 24 V | compatible with EN 61131-2 input types 1, 2 |
| Overcurrent protection | yes |
| Overcurrent protection | yes |
| Max. capacitance load CL_max[nF] | 20 |
| Voltage for operation[V] | 10...30 DC |
| Nominal insulation voltage[V] | 60 |
| Current draw[mA] | < 10; (24 V) |
| Safety feature rating | III |
| Reverse polarity safeguard | yes |
| Max. power-up delay duration[ms] | 500 |
| Activate area[mm] | 0...1.5 |
| safety disconnection distance sAs (sar)[mm] | 6 |
| Response duration when entering the enable area, activation time (ton)[ms] | 20 |
| Response duration to safety request, deactivation time (toff)[ms] | 20 |
| Risk duration / fault response time (toff max)[ms] | 100 |
| Weight[g] | 33.05 |
| Housing | Screw-type |
| Installation | recessed installation compatible |
| measurements[mm] | M12 x 1 / L = 60 |
| Thread specification | M12 x 1 |
| Substance | screw sleeve: stainless steel (1.4404 / 316L); detection surface: stainless steel (1.4404 / 316L); LED display: PEI; LED sealing: PU; securing nuts: stainless steel (1.4404 / 316L) |
| Fastening torque[Nm] | 15 |
| All-metal enclosure | yes |
Download Specification for GF762S
