Inductive Sensor Ifm IFC248

IFM CATEGORIES

Inductive Sensor Ifm ifc248

Inductive Sensor IFC248

Brand: Ifm
Product Code: IFK2007-ASI /M/US-104

  • Intended for application in machine tools and metalworking
  • Impervious to oils and coolants
  • Featuring an AS-i interface
  • Easily discernible indication of functionality and switching status
  • Durable and easily readable laser-printed label

Contact via Zalo  Contact via Zalo Phone call  Phone call
Share on:
Description Download Accessories

Product characteristics

Electrical engineering design AS-i
Detection range[mm] 7
Housing Screw-type
measurements[mm] M12 x 1 / L = 60
System gold-plated terminals
Application Lubricants and cooling fluids
Items provided
lock nuts: 2

AS-i classification

AS-i version 2.1
Enhanced addressing mode yes
AS-i I/O setup[hex] 0
AS-i ID code[hex] A.F
AS-i certificate 57101
Information bits
Overviewoutput signalnot employednot employednot employed
status = 0aim outside the operational area---
status = 1aim within the operational areainitial valueinitial valueinitial value
Weight[g] 32.8
Housing Screw-type
Installation non-recessed mountable
measurements[mm] M12 x 1 / L = 60
Thread specification M12 x 1
Substance stainless steel (1.4404 / 316L); sensing surface: uncolored LCP
Adjustment coefficient steel: 1 / stainless steel: 0.7 / brass: 0.5 / aluminum: 0.5 / copper: 0.4
Hysteresis[% of Sr] 1...20
Setting-point drift[% of Sr] -10...10

Outputs

Electrical engineering design AS-i
DC switching frequency[Hz] 100
Voltage for operation[V] 26.5...31.6 DC
Current draw[mA] < 30
Safety feature rating III
Reverse polarity safeguard yes
Max. power-up delay duration[ms] 1000
Detection range[mm] 7
Actual sensing range Sr[mm] 7 ± 10 %
Operational range[mm] 0...5.7
Surrounding temperature value[°C] -25...70
Safety feature IP 68; ("Coolant")
Display
Switching condition4 x 90° LED, yellow
Operation1 x LED, red

Download Specification for IFC248

Download PDF
