Inductive Sensor Ifm igc235

Inductive Sensor IGC235

Brand: Ifm
Product Code: IGK2012-ASI /M/US-104

  • Intended for application in machine tools and metalworking
  • Impervious to oils and coolants
  • Featuring an AS-i interface
  • Easily discernible indication of functionality and switching status
  • Durable and easily readable laser-printed label

Contact via Zalo  Contact via Zalo Phone call  Phone call
Share on:
Description Download Accessories

Product characteristics

Electrical engineering design AS-i
Detection range[mm] 12
Housing Screw-type
measurements[mm] M18 x 1 / L = 60
System gold-plated terminals
Application Lubricants and cooling fluids
Items provided
lock nuts: 2

AS-i classification

AS-i version 2.1
Enhanced addressing mode yes
AS-i I/O setup[hex] 0
AS-i ID code[hex] A.F
AS-i certificate 57301
Information bits
Overviewoutput signalnot employednot employednot employed
status = 0aim outside the operational area---
status = 1aim within the operational areainitial valueinitial valueinitial value
Weight[g] 46.4
Housing Screw-type
Installation non-recessed mountable
measurements[mm] M18 x 1 / L = 60
Thread specification M18 x 1
Substance screw sleeve: stainless steel (1.4404 / 316L); detection surface: LCP natural; securing nuts: brass
Adjustment coefficient steel: 1 / stainless steel: 0.7 / brass: 0.5 / aluminum: 0.45 / copper: 0.35
Hysteresis[% of Sr] 1...20
Setting-point drift[% of Sr] -10...10

Outputs

Electrical engineering design AS-i
DC switching frequency[Hz] 100
Voltage for operation[V] 26.5...31.6 DC
Current draw[mA] < 30
Safety feature rating III
Reverse polarity safeguard yes
Max. power-up delay duration[ms] 1000
Detection range[mm] 12
Actual sensing range Sr[mm] 12 ± 10 %
Operational range[mm] 0...9.7
Surrounding temperature value[°C] -25...70
Safety feature IP 68; ("Coolant")
Display
Switching condition4 x 90° LED, yellow
Operation1 x LED, red
