Photoelectric Sensor OGD551

Brand: Ifm
Product Code: OGDLF8KG/IO-LINK/US

Compact layout featuring a norm M18 thread and PMD time-of-flight technology
measurement with millimeter precision and ongoing distance monitoring during operation
Color-agnostic range
Concurrent output of distance measurements and reflectance enhances process reliability

Contact via Zalo

Phone call

Share on:

Description Download Accessories

Product characteristics

Kind of illumination	red illumination
Laser safety classification	1
Housing	rectangular shape shape with M18 threading
Voltage for operation[V]	18...30 DC; (cULus - Class 2 source required)
Current draw[mA]	45; (24 V)
Safety feature rating	III
Reverse polarity safeguard	yes
Kind of illumination	red illumination
Wavelength[nm]	650
Configuration options	Range / reflectance; hysteresis / threshold; sequence modulation to prevent mutual interference among up to 5 identical devices; sensitivity; current/voltage output
Weight[g]	134.8
Housing	rectangular shape shape with M18 threading
measurements[mm]	61.7 x 22.5 x 45.2
Thread specification	M18 x 1
Substance	enclosure: stainless steel (1.4404 / 316L); PPSU; ABS; PMMA; PBT/PC; EPDM; front cover: PMMA
Optical alignment	Lateral sensing

Interfaces

communication interface

IO-Link

Mode of transmission

COM2 (38,4 kBaud)

IO-Link version

1.1.3

SDCI specification

IEC 61131-9

Configurations

Operation class	Overview
0x4000	Identification and Fault Detection
0x8101	Positioning device
0x8102	ItemURI

SIO mode

yes

Necessary master port category

Minimum process cycle duration[ms]

IO-Link cyclic process data

Operation	bit length
measured value	2 x 16
device status	4
two-state switching data	2

IO-Link acyclical functions

application-specific tag; operational hours meter; switching cycle counter

Supported DeviceIDs

Mode of operation	DeviceID
Default: OGD551	1582
OGD580 / OGD581	925
OGD582 / OGD583	926
OGD585 / OGD586	1065
OGD592 / OGD593	1012
OGD596 / OGD597	1066

Note

For additional details, please refer to the IODD PDF document in the "Downloads" section

Surrounding temperature value[°C]

-25...55

Comment on operating temperature value range

At ambient temperature values < -10 °C, a warm-up duration is required

Laser is disabled

Temperature for storage[°C]

-30...80

Safety feature

IP 65; IP 67

Max. illumination spot diameter[mm]

Light spot measurements pertain to

at peak range

Background filtering[m]

< 20

Inputs

Inputs	Laser On/ Off
Total count of inputs and outputs	Count of digital outputs: 2; Count of analog outputs: 1
Overall count of outputs	2
Electrical engineering design	PNP/NPN; (customizable)
Count of digital outputs	2
Output feature	2 x typically open / default closed; (customizable)
Max. output current capacity[mA]	100
Total analog outputs	1
Analog current output[mA]	4...20; (IEC 61131-2)
Max. capacity[O]	500
Analog voltage output[V]	0...10; (IEC 61131-2)
Minimum load resistance[O]	2500
Overcurrent protection	yes
Method of overcurrent protection	yes (momentary)
Overcurrent protection	yes
Adjustment range object reflectance[%]	6...900; (reflectance; 6 % black paper; 100 % white paper)
