Photoelectric Sensor OU5018
Brand: Ifm
Product Code: OUT-HPKG/6M
- Compact enclosure designed for applications in limited spaces
- User-friendly sensitivity adjustment through a variable resistor
- Easily discernible indication of the switching status
- Wide operating voltage range
Contact via Zalo
Phone call
Product characteristics
| Kind of illumination | IR light | |
| Housing | rectangular shape | |
| Operating principle | Diffuse reflection detector | |
| Weight[g] | 283 | |
| Housing | rectangular shape | |
| measurements[mm] | 28 x 16 x 51 | |
| Substance | PPO altered | |
| Optical element composition |
| |
| Optical alignment | Lateral sensing | |
| Connection | Cable: 6 m, PVC; 3 x 0.34 mm² |
Displays / operating elements
| Display |
| ||
| Items provided |
| ||
| Surrounding temperature value[°C] | -25...80 | ||
| Safety feature | IP 67 |
Outputs
| Electrical engineering design | PNP |
| Output feature | illuminated mode |
| Max. voltage drop at switching output DC[V] | 2.5 |
| Continuous current rating of the switching output DC[mA] | 250 |
| DC switching frequency[Hz] | 160 |
| Overcurrent protection | yes |
| Method of overcurrent protection | yes (momentary) |
| Overcurrent protection | yes |
| Voltage for operation[V] | 10...55 DC |
| Current draw[mA] | 35; ((24 V)) |
| Safety feature rating | II |
| Reverse polarity safeguard | yes |
| Kind of illumination | IR light |
| Wavelength[nm] | 880 |
| Range[mm] | 1...200; (white paper 200 x 200 mm) |
| Adjustable range | yes |
| Max. illumination spot diameter[mm] | 180 |
| Light spot measurements pertain to | at peak range |
Download Specification for OU5018
