Inductive Sensor Pepperl+Fuchs NBB6-18GK10-E0-Y89851

Pepperl+Fuchs Categories

Brand: Pepperl+Fuchs
Product Code:

Share on:

Description Download Accessories

Overall specifications
transition function		normally open (NO)
Output configuration		NPN
Specified functioning distance		6 mm
mounting		flush
Output configuration		DC
Guaranteed functioning distance		0 ... 4.86 mm
diminution factor r_Al		0.2
diminution factor r_Cu		0.15
diminution factor r₃₀₄		0.62
Output configuration		3-wire
Rated specifications
Operational voltage		10 ... 30 V
commutation frequency		0 ... 500 Hz
Polarity reversal protection		reverse polarity safeguarded
Overcurrent protection		no
voltage loss		= 2 V
Operational current		0 ... 100 mA
Non-conducting current		0 ... 0.5 mA typ. 0.1 µA at 25 °C
No-load input current		= 20 mA
Parameters related to functional safety
MTTF_d		5120 a
task duration (T_M)		20 a
Diagnostic Range (DC)		0 %
Adherence to standards and directives
Compliance with standards
	Standards	EN IEC 60947-5-2
Certifications and approvals
UL certification		cULus Certified, Standard Use
Environmental conditions
Ambient temperature		-25 ... 70 °C (-13 ... 158 °F)
Mechanical characteristics
Linkage method		permanent cable with plug
Housing material		PBT
detection surface		PBT
Protection等级		IP67
Connector device		Molex
	Pin count	3
Cable
	Cable thickness	4.9 mm - 0.3 mm
	Curvature radius	> 10 x cable diameter
	Material	PVC
	Color	black
	Core count	3
	cross section of the core	0.34 mm²
	Length	750 mm
Measurements
	Length	10 mm
	Diameter	18 mm
