Inductive Sensor Pepperl+Fuchs NCN50-FP-Z2-P1

Pepperl+Fuchs Categories

Brand: Pepperl+Fuchs
Product Code:

Share on:

Description Download Accessories

Overall specifications
transition function		Normally open/closed (NO/NC)
Output configuration		Two-wire
Specified functioning distance		50 mm
mounting		non-flush
Output configuration		DC
Guaranteed functioning distance		0 ... 40.5 mm
Actual sensing distance		45 ... 55 mm typ.
diminution factor r_Al		0.4
diminution factor r_Cu		0.35
diminution factor r₃₀₄		0.8
Output configuration		2-wire
Rated specifications
Operational voltage		10 ... 60 V
commutation frequency		0 ... 80 Hz
Deadband		0 ... 20 % typ. 5 %
Polarity reversal protection		reverse polarity resistant
Overcurrent protection		pulsing
voltage loss		= 6 V
Operational current		2 ... 200 mA
Non-conducting current		0.4 ... 1 mA typ. 0.6 mA
Delay time prior to availability		= 300 ms
State indication for switching		LED, yellow
Adherence to standards and directives
Compliance with standards
	Standards	EN IEC 60947-5-2
Certifications and approvals
UL certification		cULus Certified, Standard Use
CCC certification		Approved by China Compulsory Certification (CCC)
Environmental conditions
Ambient temperature		-25 ... 70 °C (-13 ... 158 °F)
Ambient storage temperature		-25 ... 85 °C (-13 ... 185 °F)
Mechanical characteristics
Linkage method		screw terminals
cross section of the core		up to 2.5 mm²
Housing material		PBT
detection surface		PBT
Protection等级		IP67
Fastening torque, enclosure screws		1 Nm
Measurements
	Height	40 mm
	Width	80 mm
	Length	80 mm
