Inductive Sensor Pepperl+Fuchs NJ2-PD-E02-2.875-V95

Pepperl+Fuchs Categories

Brand: Pepperl+Fuchs
Product Code:

Share on:

Description Download Accessories

Item Specification
Cylinder Position Sensor

Overall specifications
transition function		normally open (NO)
Output configuration		PNP/NPN
Specified functioning distance		2 mm
mounting		flush
Output configuration		DC
Guaranteed functioning distance		0 ... 1.62 mm
diminution factor r_Al		0.4
diminution factor r₃₀₄		0.85
Output configuration		4-wire
Rated specifications
Operational voltage		10 ... 30 V DC
commutation frequency		30 Hz
Deadband		10 ... 20 % typ. 15 %
Polarity reversal protection		yes
Overcurrent protection		yes
voltage loss		= 2 V DC
Operational current		= 200 mA
Non-conducting current		= 100 µA
No-load input current		= 35 mA
Magnetic field intensity, alternating current fields		250 mT
Magnetic field strength, direct current fields		100 mT
Boundary data
Dynamic functioning pressure		3000 psi
Indicators/operation controls
LED green		Power on
Yellow indicator LED		status of output
Compliance with standards
Standards		EN 60947-5-2
Certifications and approvals
UL certification		cULus Certified, Standard Use
Environmental conditions
Ambient temperature		-25 ... 70 °C (-13 ... 158 °F)
Mechanical characteristics
Linkage method		plug connector
Protection等级		IP67
Material		Housing: zinc Sensor: aluminum
Connector device
	Threading process	7/8 inch-16 UN
	Pin count	3
Mass		222 g
Note		X = 2.875 in (73 mm)
