Inductive Sensor Pepperl+Fuchs RC10-14-N0-Y180779

Pepperl+Fuchs Categories

Brand: Pepperl+Fuchs
Product Code:

Share on:

Description Download Accessories

Overall specifications
transition function		Typically closed (NC)
Output configuration		NAMUR
Internal diameter		10 mm
Calibration cylinder
	Diameter	2.5 mm
	Length	4 mm
Output configuration		2-wire
Rated specifications
nominal voltage		8.2 V (R_i approximately 1 kΩ
commutation frequency		0 ... 2000 Hz
Current draw
	Measurement plate not found	min. 3 mA At the highest allowable ambient temperature, the current draw may reduce to 1.6 mA
	Measuring plate identified	= 1 mA
Parameters related to functional safety
MTTF_d		6150 a
task duration (T_M)		20 a
Diagnostic Range (DC)		0 %
Adherence to standards and directives
Compliance with standards
	NAMUR	EN 60947-5-6:2000 IEC 60947-5-6:1999
	Electromagnetic interference compliance	NE 21:2007
	Standards	EN IEC 60947-5-2
Certifications and approvals
ATEX certification
	Equipment protection rating Gb	PTB 99 ATEX 2128 X
UL certification		cULus Certified, Standard Use
Environmental conditions
Ambient temperature		-20 ... 65 °C (-4 ... 149 °F)
Mechanical characteristics
Linkage method		cable PVC , 2 m
cross section of the core		0.14 mm²
Housing material		PBT
Protection等级		IP67
Cable
	Curvature radius	> 10 times cable diameter
Measurements
	Height	32.5 mm
	Width	25 mm
	Length	20 mm
Overview information
Usage in hazardous environments		refer to instruction manuals
