Photoelectric Sensor Pepperl+Fuchs PSE2-SC-02

Pepperl+Fuchs Categories

Brand: Pepperl+Fuchs
Product Code:

Share on:

Description Download Accessories

Item Specification
Safety regulation module of the PSE2/PSE4 series

Boundary data
Allowed cable length		200 m
Parameters related to functional safety
Performance level (PL)		PL d
Category		Cat. 3
MTTF_d		109 a
task duration (T_M)		20 a
Diagnostic Range (DC)		87 %
Indicators/operation controls
Operational status indicator		LED green: Power activated
operation indicator		LED green
Electrical parameters
Operational voltage		24 V DC +20/-10 % 24 V AC ± 10 %
Energy usage		< 4 W
Overvoltage protection		overvoltage classification III
Output
Output signal		relay, 1 NO
Switching voltage level		230 V AC / 24 V DC
Switching capacity		3 A AC / 4 A DC
Mechanical lifespan		> 10⁷ actuation cycles
reaction time		18 ms
Output 1
Output configuration		signal output, PNP, open collector type
Switching voltage level		U_B - 1 V
Switching capacity		max. 50 mA
Compliance
Safety functionality		ISO 13849-1
Product specification		EN 12978 ; ISO 13856-2
Certifications and approvals
UL certification		cULus Certified File number: NRNT.E344450
TÜV certification		TÜV Rheinland 968/M 301.00/11
Environmental conditions
Ambient temperature		5 ... 55 °C (41 ... 131 °F)
Contamination level		2
Mechanical characteristics
Protection等级		IP20
Linkage		screw terminals, conductor cross section 2 x 1 mm²
Material		PC / PA black
Mass		approx. 150 g
Measurements
	Height	100 mm
	Width	22.5 mm
	Depth	120 mm
