Datasheet excerpt: Technical data of FYQLA1-140R-3
| Overall specifications | ||
|---|---|---|
| mounting | Logic level amplifier must be housed in a NEMA-rated sealed enclosure | |
| Output configuration | DC | |
| Delay time prior to availability | 3 s | |
| Output configuration | Relay output electrical lifespan: contact rating of 250 V AC @ 5A for a minimum of 100k cycles | |
| UL File ID | E179102 | |
| Rated specifications | ||
| Operational voltage | 120 V AC ± 15% , 45 ... 65 Hz | |
| Parameters related to functional safety | ||
| Error response time | < 4 s | |
| Indicators/operation controls | ||
| operation indicator | Fault Detected: Flashing LED Red | |
| LED green | relay closed | |
| LED red | relay Open | |
| Electrical parameters | ||
| Voltage rating | Energy loss 3 VA | |
| Output | ||
| Current | continuous current 5 mA to 5 A (normally open (NO) contact) | |
| reaction time | < 20 ms ( switch open to contact open ) | |
| Compliance with standards | ||
| Standards | ISO 13849-1:2023 Category 3 PL d EN 63000:2018 EN 61326-3-1:2017 EN 60664-1:2020 |
|
| Certifications and approvals | ||
| UL certification | cULus Certified, Standard Use UL 508 |
|
| Environmental conditions | ||
| Ambient temperature | -40 ... 70 °C (-40 ... 158 °F) -20 ... 50 °C (-4 ... 122 °F) @ max. load |
|
| Ambient storage temperature | -40 ... 70 °C (-40 ... 158 °F) | |
| Mechanical characteristics | ||
| Linkage method | earth screw terminal, max 2.5 mm2 | |
| Housing material | 304 Stainless steel | |
| Protection等级 | IP20, Class 1 suitable for indoor applications only | |
| Measurements | ||
| Width | 135 mm | |
| Depth | 58 mm | |
| Length | 203 mm | |
| Mounting | Panel installation | |
| Note | Compatible with a maximum of six 50FY41 series sensors | |
| Overview information | ||
| Note | Packaged with ten 22 kΩ resistors |
|
Classifications
| Configuration | Classification code |
|---|---|
| ECLASS 13.0 | 19200504 |
| ECLASS 12.0 | 19200504 |
| ECLASS 11.0 | 19200504 |
| ECLASS 10.0.1 | 19200504 |
| ECLASS 9.0 | 19200504 |
| ECLASS 8.0 | 27279211 |
| ECLASS 5.1 | 27279211 |
| ETIM 9.0 | EC001418 |
| ETIM 8.0 | EC001418 |
| ETIM 7.0 | EC001418 |
| ETIM 6.0 | EC001418 |
| ETIM 5.0 | EC003015 |
| UNSPSC 12.1 | 41113650 |
