Sensor Accessory Pepperl+Fuchs KE5D2-6H/2R-S

Pepperl+Fuchs Categories

Sensor Accessory KE5D2-6H/2R-S

Brand: Pepperl+Fuchs
Product Code:

Contact via Zalo

Phone call

Share on:

Description Download Accessories

Datasheet excerpt: Technical data of KE5D2-6H/2R-S

Classifications

Item Specification
Safety controller

Overall specifications
UL File ID		E179102
Supply
nominal voltage		24 V AC/V DC ( for AC, 45 ... 62 Hz )
nominal current		< 0 . 5 A
Energy usage		< 12 W
Indicators/operation controls
LED green		power
LED red		Sensor status (one per channel/two per input configuration)
LED red/green indicator		relay : ( 2 ) red , ( 2 ) green
Transition state		LED red flashing: error indication
Input
Input type		(6) specialized input devices for the 50FY41-.. series
Supply voltage		12 V DC, (2 channel, sink/source)
Output
Current		5 mA to 5 A (Non-contact)
Relay
	Switching voltage level	20 ... 230 V AC/DC
	Switching capacity	Refer to the manual specifications for detailed information regarding currents and cycles
	Mechanical lifespan	> 1,000,000 cycles
Output I		2 output relays, normally open contact
reaction time		20 ms (switch disengaged to contact released)
Transfer properties
Delay time prior to availability		3 s
Adherence to standards and directives
Compliance with directives
	Machinery Directive 2006/42/EC	EN/ISO 13849-1:2023 category 3 PL d
	Low Voltage Directive 2006/95/EC	EN 60664-1:2020
	EMC Regulation 2004/108/EC	EN 61326-1:2021
Compliance with standards
	Electromagnetic interference compliance	EN 61326-1:2017
	Standards	EN 55011:2016+A1:2017+A11:2020+A2:2021 CISPR 11: 2015+A1:2016+A2:2019
Certifications and approvals
UL certification		UL 508
Environmental conditions
Ambient temperature		-20 ... 50 °C (-4 ... 122 °F)
Mechanical characteristics
Protection等级		IP20
Linkage		screw terminal connection, maximum 2.5 mm²
Mass		approx. 545 g
Measurements
	Height	99 mm
	Width	67.8 mm
	Length	107 mm
Mounting		DIN rail mounting
