Temperature Sensor Turck TS700-L050-30-LI2UPN8-H1141
TURCK CATEGORIES
Temperature Sensor TS700-L050-30-LI2UPN8-H1141
Brand: Turck
Product Code: 100004381
Country of origin: DE
- Screw-type adapter featuring a G1/2" male thread process connection included in the delivery
- 4-digit, dual-colored, 12-segment display, adjustable for 180° rotation
- Upper section of the housing can be rotated to a maximum of 340°
- Components in contact with media: 1.4404 (316L), CR O-ring, AFM34 flat seal
- Immersion length: 50 mm
- 17…33 VDC
- NO/NC terminal, PNP/NPN output, analog output (current/voltage), IO-Link
- Multiple IO-Link mapping profiles are available for selection
Contact via Zalo
Phone call
General data
| Place of manufacture | DE |
| Weight | 390 g |
Technical Data
| Sensing method | interface contact |
| Design type | Featuring display (integrated probe) |
| Measurement range | -50…150 °C |
| L immersion depth | 50 mm |
| Process interface | G 1/2? tapered male thread |
| Supply voltage | 17…33 VDC |
| Electrical yield | Switching output signal, Present output (3-wire), Voltage output (3-wire), IO-Link |
| Voltage output | 0…10 V |
| Output of current | 4…20 mA |
| Communication standard | IO-Link |
| Sensing element | Pt1000 |
| Type of connection | Connector, M12 × 1 |
| Enclosure material | Corrosion-resistant steel/Plastic, 1.4404 (AISI 316L)/Grilamid TR90 UV |
| Surrounding temperature | -40…+80 °C |
| Safety rating | IP66/IP67/IP69K |
| Certifications | CE, cULus |
Download Specification for TS700-L050-30-LI2UPN8-H1141
