Ultrasonic Sensor Turck RU600D-M30M-LIU8X2-H1141
TURCK CATEGORIES
Ultrasonic Sensor RU600D-M30M-LIU8X2-H1141
Brand: Turck
Product Code: 100039015
Country of origin: DE
- Smooth ultrasonic transducer surface
- M30 circular configuration, encapsulated
- Connection through M12 × 1 plug, male plug
- Measurement range configurable through teach-in
- Thermal adjustment
- Obstructed area: 60 cm
- Range: 600 cm
- Definition of resolution: 1 mm
- Variable switching hysteresis
- Sonic cone aperture angle: ± 5 °
- 1 × PNP output for switching/NPN, IO-Link, teach-in, synchronization
- 1 × analog output, 4…20 mA/0…10 V/switching output, PNP/NPN
- NO/NC configurable
- Conveyance of process value and parameter setup through IO-link
- Configurable functionality as a retroreflective sensor
Contact via Zalo
Phone call
General data
| Place of manufacture | DE |
| Weight | 191 g |
Technical Data
| Operation | Proximity sensor |
| Operationing mode | Time-of-Flight |
| Design type | Screwed barrel |
| Dimension | M30 x 1.5 |
| Radiation angle | straight |
| Range | 600…6000 mm |
| Definition of resolution | 1 mm |
| Supply voltage | 18…30 VDC |
| Switching component operation | NO/NC |
| Output category | PNP/NPN, continuous output |
| Voltage output | 0…10 V |
| Output of current | 4…20 mA |
| Communication standard | IO-Link |
| Type of connection | Connector, M12 × 1 |
| Enclosure material | Metal, CuZn, Nickel Plated |
| Surrounding temperature | -25…+70 °C |
| Safety rating | IP67 |
| Certifications | CE, cULus |
| Unique characteristics | Synchronization, teaching input, chemical resistant |
Download Specification for RU600D-M30M-LIU8X2-H1141
Download PDF
