Capacitive Sensor Ifm KG5079
IFM CATEGORIES
Capacitive Sensor KG5079
Brand: Ifm
Product Code: KG-2080-N/6M/1D/1G
- Suitable for use in hazardous environments
- Simplified adjustment of the sensing range using a variable resistor
- Easily discernible indication of the switching status
- For detecting positions or monitoring levels
Contact via Zalo
Phone call
Product characteristics
| Electrical engineering design | NAMUR |
| Output feature | default closed |
| Detection range[mm] | 8 |
| Housing | Screw-type |
| measurements[mm] | M18 x 1 / L = 84 |
| Connection at signal amplifier | yes |
| Amplifiers for switching applications | connection to certified intrinsically safe circuits with the maximum values: U = 15 V / I = 50 mA / P = 120 mW |
| Rated voltage DC[V] | 8.2; (1kO) |
| DC supply voltage[V] | 7.5...15 |
| Current draw[mA] | < 1; (disabled; conductive: > 2,2) |
| Safety feature rating | II |
Mechanical data
| Weight[g] | 320 | ||
| Housing | Screw-type | ||
| Installation | non-recessed mountable | ||
| measurements[mm] | M18 x 1 / L = 84 | ||
| Thread specification | M18 x 1 | ||
| Substance | PBT | ||
| Display |
| ||
| Surrounding temperature value[°C] | -20...60 | ||
| Safety feature | IP 67 |
Monitoring range
| Detection range[mm] | 8 | |
| Adjustable sensing range | yes | |
| sensing range set at the factory[mm] | 8 | |
| Actual sensing range Sr[mm] | 8 ± 10 % | |
| Electrical engineering design | NAMUR | |
| Output feature | default closed | |
| DC switching frequency[Hz] | 4 | |
| Adjustment coefficient | glass: 0.4 / water: 1 / ceramics: 0.2 / PVC: 0.2 | |
| Hysteresis[% of Sr] | 1...15 | |
| Setting-point drift[% of Sr] | -15...15 | |
| Items provided |
|
Download Specification for KG5079
