Capacitive Sensor Ifm KI503A
IFM CATEGORIES
Capacitive Sensor KI503A
Brand: Ifm
Product Code: KIE4150NCPKG/3D
- Suitable for use in hazardous environments
- Simplified adjustment of the sensing range using a variable resistor
- Easily discernible indication of the switching status
- Direct integration with plant control systems without the need for a switching amplifier
- Supplementary output functionality NO/NC
Contact via Zalo
Phone call
Product characteristics
| Electrical engineering design | PNP |
| Output feature | supplementary |
| Detection range[mm] | 15 |
| Housing | Screw-type |
| measurements[mm] | M30 x 1.5 / L = 150 |
| Voltage for operation[V] | 10...30 DC |
| Current draw[mA] | < 20 |
| Safety feature rating | III |
| Reverse polarity safeguard | yes |
| Measuring method | capacitive |
| Weight[g] | 149 |
| Housing | Screw-type |
| Installation | non-recessed mountable |
| measurements[mm] | M30 x 1.5 / L = 150 |
| Thread specification | M30 x 1.5 |
| Substance | PBT; PA |
| Connection | terminals: 0.34...1.5 mm²; Cable sheath: Ø 5...9 mm; Cable connector: M20 × 1.5 |
Displays / operating elements
| Display |
| ||
| Items provided |
| ||
| Surrounding temperature value[°C] | -20...60 | ||
| Safety feature | IP 65; IP 67 |
Monitoring range
| Detection range[mm] | 15 |
| Adjustable sensing range | yes |
| sensing range set at the factory[mm] | 15 |
| Actual sensing range Sr[mm] | 15 ± 10 % |
| Electrical engineering design | PNP |
| Output feature | supplementary |
| Max. voltage drop at switching output DC[V] | 2.5 |
| Max. stray current[mA] | 0.1 |
| Continuous current rating of the switching output DC[mA] | 200 |
| DC switching frequency[Hz] | 10 |
| Overcurrent protection | yes |
| Method of overcurrent protection | yes (momentary) |
| Short-circuit resistant | yes |
| Overcurrent protection | yes |
| Hysteresis[% of Sr] | 1...15 |
| Setting-point drift[% of Sr] | -20...20 |
Download Specification for KI503A
