Photoelectric Sensor Ifm OMH555
IFM CATEGORIES
Photoelectric Sensor OMH555
Brand: Ifm
Product Code: OMHLF8KG/IO-Link/US
- Optical distance measurement within the micrometer scale
- Dual switching outputs
- Appropriate for applications with high frequency
- With three operational modes and a durable, compact design, a broad spectrum of applications is supported
Contact via Zalo
Phone call
Product characteristics
| Kind of illumination | red illumination |
| Laser safety classification | 1 |
| Housing | rectangular shape |
| Voltage for operation[V] | 18...30 DC; (cULus - Class 2 source required) |
| Current draw[mA] | < 30 |
| Safety feature rating | III |
| Reverse polarity safeguard | yes |
| Activation delay time[s] | < 0.3 |
| Kind of illumination | red illumination |
| Wavelength[nm] | 630 |
| Typ. lifetime[h] | 50000 |
| Temperature adjustment | yes |
| Linearity error of analog output[%] | ±0,22 |
| Comments on the precision / variation | The specified values are attained following a warm-up duration of 20 minutes |
Software / programming
| Configuration options | hysteresis / range / 2-point; delay on switch-on and switch-off; switch-on actions; teach function; filter; light-on/negative logic mode; laser deactivation; mode of operation | ||||||||
| communication interface | IO-Link | ||||||||
| Mode of transmission | COM2 (38,4 kBaud) | ||||||||
| IO-Link version | 1.1 | ||||||||
| SDCI specification | IEC 61131-9 | ||||||||
| Configurations | Measuring and switching sensor, single channel, identification and diagnostics, sensor management, teach two values, locator, product URI | ||||||||
| SIO mode | yes | ||||||||
| Necessary master port category | A | ||||||||
| Minimum process cycle duration[ms] | 3.2 | ||||||||
| IO-Link cyclic process data |
| ||||||||
| IO-Link acyclical functions | application-specific label; runtime meter | ||||||||
| Supported DeviceIDs |
| ||||||||
| Note |
| ||||||||
| Adjustable range | yes | ||||||||
| Max. illumination spot diameter[mm] | 1 | ||||||||
| Light spot measurements pertain to | at peak range |
Inputs
| Inputs | Laser On/ Off | |
| Quantity of digital inputs | 1 | |
| Total count of inputs and outputs | Total digital inputs: 1; Total digital outputs: 1; Total analog outputs: 1 | |
| Overall count of outputs | 2 | |
| Electrical engineering design | PNP/NPN; (customizable) | |
| Count of digital outputs | 1 | |
| Output feature | typically open / closed; (customizable) | |
| Max. voltage drop at switching output DC[V] | 2.2 | |
| Continuous current rating of the switching output DC[mA] | 100 | |
| DC switching frequency[Hz] | 150 | |
| Observations regarding switching frequency[Hz] |
| |
| Total analog outputs | 1 | |
| Analog current output[mA] | 4...20; (IEC61131-2) | |
| Max. capacity[O] | 500 | |
| Analog voltage output[V] | 0...10; (IEC 61131-2) | |
| Minimum load resistance[O] | 5000 | |
| Overcurrent protection | yes | |
| Overcurrent protection | yes | |
| Measuring span[m] | 0.05...0.5; (6...90% remission) | |
| Surrounding temperature value[°C] | 0...60 | |
| Temperature for storage[°C] | -10...65 | |
| Safety feature | IP 65; IP 67 |
Download Specification for OMH555
