Photoelectric Sensor Ifm OU5005

IFM CATEGORIES

Brand: Ifm
Product Code: OUS-OOKG

Extensive range
Compact enclosure designed for applications in limited spaces
Elevated protection rating to meet the demands of challenging industrial conditions
Wide operating voltage range

Share on:

Description Download Accessories

Kind of illumination

IR light

Housing

rectangular shape

Operating principle

Opposed beam sensor

Weight[g]

138

Housing

rectangular shape

measurements[mm]

28 x 16 x 51

Substance

PPO altered

Optical element composition

glass

Optical alignment

Lateral sensing

Connection

Cable: 2 m, PVC; 2 x 0.34 mm²

Display

Power

1 x LED, yellow

Items provided

Angle bracket: 1, E20211

Surrounding temperature value[°C]

-25...80

Safety feature

IP 67

Overcurrent protection	yes
Method of overcurrent protection	yes (momentary)
Overcurrent protection	yes
Voltage for operation[V]	10...55 DC
Current draw[mA]	20; ((24 V))
Safety feature rating	II
Reverse polarity safeguard	yes
Kind of illumination	IR light
Wavelength[nm]	880
Transducer / detector	signal generator
Range[m]	< 6
Adjustable range	no
Max. illumination spot diameter[mm]	734
Light spot measurements pertain to	at peak range
