Pressure Sensor Ifm PC9013
IFM CATEGORIES
Pressure Sensor PC9013
Brand: Ifm
Product Code: PT-075PSBU76-B-DVG/US/ /W
- Accurate linear 0...10 V output signal
- Excellent repeatability with minimal linearity deviation
- Features long-term stability due to robust overload protection
- Durable stainless steel enclosure designed for demanding industrial settings
- Broad operating temperature value range and elevated protection rating
Contact via Zalo
Phone call
Product characteristics
| Total count of inputs and outputs | Count of analog outputs: 1 | ||
| Measuring span |
| ||
| Connection for process | screw connection 7/16" - 20 UNF with internal thread | ||
| Application | for commercial applications | ||
| Media | fluids and gases | ||
| Intermediate temperature value[°C] | -25...90 | ||
| Minimum force per unit area before bursting |
| ||
| Pressure classification |
| ||
| Kind of force per unit area | relative force per unit area | ||
| Surrounding temperature value[°C] | -25...90 | ||
| Temperature for storage[°C] | -40...100 | ||
| Safety feature | IP 67; IP 69K | ||
| Connection | Connector: 1 x M12; coding: A |
Tests / approvals
| Weight[g] | 74.5 | ||
| Housing | cylindrical | ||
| measurements[mm] | Ø 22 / L = 61.7 | ||
| Substance | stainless steel (1.4404 / 316L); PA | ||
| Substances (contacted components) | stainless steel (1.4404 / 316L) | ||
| Minimum force per unit area cycles | 50 million | ||
| Connection for process | screw connection 7/16" - 20 UNF with internal thread | ||
| Measuring span |
|
Inputs / outputs
| Total count of inputs and outputs | Count of analog outputs: 1 |
| Voltage for operation[V] | 16...36 DC |
| Current draw[mA] | < 6 |
| Minimum insulation resistance[MO] | 100; (500 V DC) |
| Safety feature rating | III |
| Reverse polarity safeguard | yes |
| Overall count of outputs | 1 |
| Output response | analog signal |
| Total analog outputs | 1 |
| Analog voltage output[V] | 0...10 |
| Minimum load resistance[O] | 2000 |
| Reproducibility[% of the span] | < ± 0,1; (with temperature value fluctuations < 10 K) |
| Characteristics variation[% of the span] | < ± 1,4; (incl. drift due to tightening torque, zero and span error) |
| Linearity variation[% of the span] | < ± 0.25 (BFSL) / < ± 0.5 (LS) |
| Hysteresis variation[% of the span] | < ± 0,3 |
| Extended stability[% of the span] | < ± 0,1; (per 6 months) |
| Temperature coefficient value for the zero reference[% of the span / 10 K] | < ± 0,1; (-25...90 °C) |
| Temperature coefficient value for the range[% of the span / 10 K] | < ± 0,1; (-25...90 °C) |
