Pressure Sensor Ifm PC9050
IFM CATEGORIES
Pressure Sensor PC9050
Brand: Ifm
Product Code: PT-400-SBG14-C-DVG/ /W
- Accurate linear 0.5...4.5 V output signal for portable applications
- Excellent repeatability with minimal linearity deviation
- Features long-term stability due to robust overload protection
- Durable stainless steel enclosure designed for mobile machinery
- Broad operating temperature value range and elevated protection rating
Contact via Zalo
Phone call
Product characteristics
| Total count of inputs and outputs | Count of analog outputs: 1 | ||
| Measuring span |
| ||
| Connection for process | screw connection G 1/4 with outdoor threading | ||
| Application | for portable applications | ||
| Media | fluids and gases | ||
| Intermediate temperature value[°C] | -25...90; (on request: -40...100 °C) | ||
| Minimum force per unit area before bursting |
| ||
| Pressure classification |
| ||
| Kind of force per unit area | relative force per unit area | ||
| Step response duration for analog output[ms] | 8 |
Operating conditions
| Surrounding temperature value[°C] | -25...90 | ||
| Temperature for storage[°C] | -40...100 | ||
| Safety feature | IP 67; IP 69K | ||
| Measuring span |
|
Inputs / outputs
| Total count of inputs and outputs | Count of analog outputs: 1 |
| Voltage for operation[V] | 5 DC; (ratiometric) |
| Current draw[mA] | < 6 |
| Minimum insulation resistance[MO] | 100; (80 V DC) |
| Safety feature rating | III |
| Reverse polarity safeguard | yes |
| Overall count of outputs | 1 |
| Output response | analog signal |
| Total analog outputs | 1 |
| Analog voltage output[V] | 0.5...4.5 |
| Minimum load resistance[O] | 5000 |
| Reproducibility[% of the span] | < ± 0,1; (with temperature value fluctuations < 10 K) |
| Characteristics variation[% of the span] | < ± 1,0; (incl. drift due to tightening torque, zero and span error) |
| Linearity variation[% of the span] | < ± 0.25 (BFSL) / < ± 0.5 (LS) |
| Hysteresis variation[% of the span] | < ± 0,2 |
| Extended stability[% of the span] | < ± 0,1; (per 6 months) |
| Temperature shift per 10 K | < ± 0.5 |
| Weight[g] | 80.5 |
| Housing | cylindrical |
| measurements[mm] | Ø 22 / L = 65.1 |
| Substance | stainless steel (1.4404 / 316L); PA |
| Substances (contacted components) | stainless steel (1.4404 / 316L); FKM |
| Minimum force per unit area cycles | 50 million |
| Connection for process | screw connection G 1/4 with outdoor threading |
| Integrated restrictor component | yes |
Download Specification for PC9050
