Capacitive Sensor Pepperl+Fuchs CBB4-12GH70-E0
Pepperl+Fuchs Categories
Contact via Zalo
Phone call
Datasheet excerpt: Technical data of CBB4-12GH70-E0
| Overall specifications | ||
|---|---|---|
| transition function | normally open (NO) | |
| Output configuration | NPN | |
| Specified functioning distance | 4 mm | |
| mounting | flush | |
| Output configuration | DC | |
| Guaranteed functioning distance | 0 ... 2.88 mm | |
| Output configuration | 3-wire | |
| Rated specifications | ||
| mounting requirements | ||
| A | 0 mm | |
| B | 0 mm | |
| C | 15 mm | |
| F | 15 mm | |
| Operational voltage | 10 ... 36 V DC | |
| commutation frequency | 0 ... 50 Hz | |
| Polarity reversal protection | reverse polarity safeguarded | |
| Overcurrent protection | pulsing | |
| voltage loss | = 2.5 V | |
| Operational current | 0 ... 100 mA | |
| No-load input current | = 12 mA | |
| State indication for switching | LED, yellow | |
| Indicators/operation controls | ||
| variable resistor | Sensitivity calibration | |
| Adherence to standards and directives | ||
| Compliance with standards | ||
| Standards | EN IEC 60947-5-2 | |
| Certifications and approvals | ||
| UL certification | cULus Certified, Standard Use | |
| Environmental conditions | ||
| Ambient temperature | -25 ... 70 °C (-13 ... 158 °F) | |
| Mechanical characteristics | ||
| Linkage method | cable PUR , 2 m | |
| cross section of the core | 0.34 mm2 | |
| Housing material | Stainless steel 1.4404 / AISI 316L | |
| detection surface | PEEK | |
| Protection等级 | IP65 | |
| Measurements | ||
| Length | 70 mm | |
| Diameter | 12 mm | |
Classifications
| Configuration | Classification code |
|---|---|
| ECLASS 13.0 | 27274201 |
| ECLASS 12.0 | 27274201 |
| ECLASS 11.0 | 27270102 |
| ECLASS 10.0.1 | 27270102 |
| ECLASS 9.0 | 27270102 |
| ECLASS 8.0 | 27270102 |
| ECLASS 5.1 | 27270102 |
| ETIM 9.0 | EC002715 |
| ETIM 8.0 | EC002715 |
| ETIM 7.0 | EC002715 |
| ETIM 6.0 | EC002715 |
| ETIM 5.0 | EC002715 |
| UNSPSC 12.1 | 39121550 |
Download Specification for CBB4-12GH70-E0
