Capacitive Sensor Pepperl+Fuchs PB1-008-6

Pepperl+Fuchs Categories

Brand: Pepperl+Fuchs
Product Code:

Share on:

Description Download Accessories

Item Specification
Handheld Button

Overall specifications
Specification		hand sensitive actuation
Rated specifications
Operational voltage		120 V AC / 45 - 60 Hz
Current draw		40 mA
Indicators/operation controls
Transition state		1 LED
Output
Quantity/Classification		2 NO; 2 NC
Output configuration		contact assembly ; Relay output (contacts are unidirectionally guided)
Switching voltage level		max. 250 V AC
Switching capacity		1 A AC/DC (resistive and inductive load)
Activation delay		= 60 ms
Turn-off delay		= 80 ms
Mechanical lifespan		= 5 x 10⁷
Electrical lifespan		= 5 x 10⁶
Electromagnetic interference compliance
Electrostatic discharge (ESD)
	Contact discharge	8 kV
Electromagnetic radiation fields
	Radio frequency resilience IEC61000-4-3	10 V/m , refer to note 1
	Burst IEC 61000-4-4	4 kV
	Surge IEC 61000-4-5	symmetrical: 1000 V asymmetrical: 2000 V
Noise immunity conducted according to IEC 61000-4-6		10 V _rms , refer to note 1
Certifications and approvals
UL certification		UL 991
CSA certification		CSA C22.2, No. 14
Environmental conditions
Ambient temperature		-18 ... 50 °C (0 ... 122 °F)
Impact resistance		45 g for 2 ms
Mechanical characteristics
Linkage method		screw terminals
Protection等级		IP64
Material		Handheld Button: Noryl N190 Protective cover Noryl N190
Note		Handheld Button
