Datasheet excerpt: Technical data of LSR 04-1,6-0,85-WC12M6
| Item Specification | ||
|---|---|---|
| Fiber optic glass - diffuse with silicone coating | ||
| Overall specifications | ||
|---|---|---|
| length of fiber optic cable | 850 mm | |
| Diameter of fiber optic | 7.5 mm | |
| Adapter configuration | 04 | |
| End cap | Threaded / cylindrical right angle | |
| Curvature radius | min. 25 mm | |
| fiber bundle width | 1.6 mm optical face: 2 mm2 |
|
| Fiber setup | optically isolated | |
| angle of opening | approx. 68 ° | |
| Certifications and approvals | ||
| Certifications | CE | |
| Environmental conditions | ||
| Ambient temperature | -20 ... 85 °C (-4 ... 185 °F) -40 ... 180 °C (-40 ... 356 °F) |
|
| Ambient storage temperature | -20 ... 85 °C (-4 ... 185 °F) | |
| Mechanical characteristics | ||
| Protection等级 | IP65 | |
| Material | ||
| optical surface | glass | |
| Insulation | silicone | |
| Core | Glass filament | |
| End cap | Stainless steel 1.4305 / AISI 303 | |
| Adapter | ABS | |
| Fastening torque for securing screws | max: 1 Nm | |
| Pulling force | at probe at 20°C: 60 N | |
| Fiber optic signal boosters | ||
| Product range | MLV41-LL IR MLV41-LL RT |
|
