Cylinder Sensor Ifm MR0102
IFM CATEGORIES
Cylinder Sensor MR0102
Brand: Ifm
Product Code: MRT2021BAKOA/R/0,3M/ASR
- Self-locking bracket for rapid installation and straightforward adjustment
- Simple insertion of 'drop from the top' into a slot
- Molded cable offers excellent strain relief
- Featuring a combined AC/DC output and utilizing two-wire technology
- Extremely high switching frequency
Contact via Zalo
Phone call
Product characteristics
| Electrical engineering design | PNP/NPN | ||
| Output feature | typically open | ||
| measurements[mm] | 30.5 x 5 x 6.5 | ||
| Voltage for operation[V] | 5...50 AC / 5...60 DC; (UL supply class 2: 5...60 DC / 5...30 AC) | ||
| Safety feature rating | III | ||
| Reverse polarity safeguard | yes | ||
| Reverse polarity safeguard | yes | ||
| Items provided |
|
Mechanical data
| Weight[g] | 14.5 | ||
| Installation | recessed installation compatible | ||
| Cylinder design | T-slot actuators | ||
| measurements[mm] | 30.5 x 5 x 6.5 | ||
| Substance | enclosure: PA; retention clamp: stainless steel | ||
| Switching cycles in connection with PLC[Mio] | < 40 | ||
| Display |
| ||
| Max. descending time[ms] | 0.1 | ||
| Max. production time including bounce[ms] | 0.6 |
Monitoring range
| Magnetic responsiveness[mT] | 2.1 |
| Movement velocity[m/s] | 10 |
| Electrical engineering design | PNP/NPN |
| Output feature | typically open |
| Max. voltage drop at switching output DC[V] | 5 |
| Max. voltage drop at switching output AC[V] | 5 |
| Continuous current rating of the switching output AC[mA] | 100; (External protective circuit for inductive load (valve, contactor, etc.) necessary.) |
| Continuous current rating of the switching output DC[mA] | 100; (External protective circuit for inductive load (valve, contactor, etc.) necessary.) |
| AC switching frequency[Hz] | 1000 |
| DC switching frequency[Hz] | 1000 |
| Max. switching capacity[W] | 10 |
| Overcurrent protection | no |
| Short-circuit resistant | no |
| Overcurrent protection | no |
| Hysteresis[mm] | 1 |
| Reproducibility[mm] | -0.2...0.2 |
| Surrounding temperature value[°C] | -25...70 |
| Safety feature | IP 65; IP 67 |
| Necessary safeguarding | miniature fuse in accordance with IEC60127-2 sheet 1; = 0.175 A; quick acting |
Download Specification for MR0102
