Photoelectric Sensor RMS-D-RC-NA1

Brand: Pepperl+Fuchs
Product Code:

Contact via Zalo

Phone call

Share on:

Description Download Accessories

Datasheet excerpt: Technical data of RMS-D-RC-NA1

Classifications

Item Specification
FCC-approved premium radar motion sensor with enhanced features, dynamic model that provides direction detection, remotely controllable, 2 m x 4.5 m detection range, maximum installation height of 4 m, black casing, relay contact output, and cable connection

Overall specifications
detection range		Measurements: 2000 x 4500 mm (D x W) at a mounting height of 2200 mm and an inclination angle of 30° narrow: 4500 x 2000 mm (D x W) at a mounting height of 2200 mm and an inclination angle of 30°
functioning principle		Microwave component
Detection rate		min. 0.1 m/s
adjustment angle		Horizontal: -30° ... +30° in 5° steps Vertical: 0° ... 90° in 10° steps
Operating frequency range		24.075 ... 24.175 GHz K-Band
Operation mode		Radar-based motion detector
Transmitter emitted power (EIRP)		< 20 dBm
Parameters related to functional safety
MTTF_d		640 a
task duration (T_M)		20 a
Diagnostic Range (DC)		0 %
Indicators/operation controls
operation indicator		LED red/green indicator
control components		DIP switch for selecting functioning modes: direction detection, cross-traffic suppression, slow motion, switching type
control components		Sensitivity calibration
control components		Adjustment for off delay
Electrical parameters
Operational voltage		12 ... 36 V DC , 12 ... 28 V AC
No-load input current		= 50 mA at 24 V DC
Energy usage		= 1.2 W at 24 V DC = 1.7 W at 36 V DC
Output
Type of switch		NO/NC
Output signal		Relay, 1 normally open (NO) contact / normally closed (NC) contact
Switching voltage level		max. 48 V AC / 48 V DC
Switching capacity		max. 0.5 A AC / 1 A DC
Conversion power		max. 24 W / 60 VA
delay in a de-energized state		0.2 ... 5 s customizable (factory preset at 1 sec)
Certifications and approvals
FCC certification		FCC Regulations part 15 / This device is permissible for use in the USA
Integrated Circuit approval		RSS210 Issue 8.0 / This device is approved for use in Canada
Certifications		Use in countries of the European Union is prohibited. In other countries, all relevant national regulations must be adhered to
Environmental conditions
Functional temperature range		-20 ... 60 °C (-4 ... 140 °F)
Ambient storage temperature		-30 ... 70 °C (-22 ... 158 °F)
Comparative moisture content		max. 90% non-condensing
Mechanical characteristics
mounting height		max. 4000 mm
Protection等级		IP54
Linkage		4-pin plug, 5 m connecting cable included with shipment
Material
	Housing	PC/ABS black color
Mass		120 g
Measurements		123 mm x 65 mm x 57 mm
	Height	65 mm
	Width	123 mm
	Depth	57 mm
Suitable series
Series		RMS
